ACE-661C |
Pick-up Device: 1/4" SHARP CCD |
|
Effective Pixels: 542(h)x582(v) |
Horizontal Resolution: 420 Lines |
Minimum Illumination: 1.0 lux |
S/N Ratio: More than 48DB |
| Electronic Shutter: |
1/60~1/100.000 sec |
Auto Iris lens: VIDEO/DC |
Power: DC 12V |
Dimension: 115mmx60mmx48mm |
|
|
ACE-662C |
Pick-up Device: 1/3" SHARP CCD |
|
Effective Pixels: 542(h)x582(v) |
Horizontal Resolution: 420 Lines |
Minimum Illumination: 0.9 lux |
S/N Ratio: More than 48DB |
| Electronic Shutter: |
1/50~1/100.000 sec |
Auto Iris lens: VIDEO/DC |
Power: DC 12V |
Dimension: 115mmx60mmx48mm |
| |
|
ACE-663C |
Pick-up Device: 1/3" SONY CCD |
|
Effective Pixels: 542(h)x582(v) |
Horizontal Resolution: 420 Lines |
Minimum Illumination: 0.5 lux |
S/N Ratio: More than 48DB |
| Electronic Shutter: |
1/50~1/100.000 sec |
Auto Iris lens: VIDEO/DC |
Power: DC 12V |
Dimension: 115mmx60mmx48mm |
| |
|
ACE-664C |
Pick-up Device: 1/3" SONY CCD |
|
Effective Pixels: 752(h)x582(v) |
Horizontal Resolution: 480 Lines |
Minimum Illumination: 0.1 lux |
S/N Ratio: More than 52DB |
| Electronic Shutter: |
1/50~1/100.000 sec |
Auto Iris lens: VIDEO/DC |
Power: DC 12V |
Dimension: 115mmx60mmx48mm |
| |
|
ACE-665C |
Pick-up Device: 1/3" SONY CCD |
|
Effective Pixels: 752(h)x582(v) |
Horizontal Resolution: 480 Lines |
Minimum Illumination: 0.01 lux |
S/N Ratio: More than 60DB |
Electronic Shutter: 2X Zoom |
Auto Iris lens: VIDEO/DC |
Power: DC 12V |
Dimension: 115mmx60mmx48mm |
| |
|
ACE-611C |
Pick-up Device: 1/4" SHARP CCD |
|
Effective Pixels: 542(h)x582(v) |
Horizontal Resolution: 420 Lines |
Minimum Illumination: 1.0 lux |
S/N Ratio: More than 48DB |
| Electronic Shutter: |
1/60~1/100.000 sec |
Auto Iris lens: VIDEO/DC |
Power: DC 12V |
Dimension: 115mmx60mmx48mm |
| |
|
ACE-612C |
Pick-up Device: 1/3" SHARP CCD |
|
Effective Pixels: 542(h)x582(v) |
Horizontal Resolution: 420 Lines |
Minimum Illumination: 0.9 lux |
S/N Ratio: More than 48DB |
| Electronic Shutter: |
1/50~1/100.000 sec |
Auto Iris lens: VIDEO/DC |
Power: DC 12V |
Dimension: 115mmx60mmx48mm |
| |
|
ACE-613C |
Pick-up Device: 1/3" SONY CCD |
|
Effective Pixels: 542(h)x582(v) |
Horizontal Resolution: 420 Lines |
Minimum Illumination: 0.5 lux |
S/N Ratio: More than 48DB |
| Electronic Shutter: |
1/50~1/100.000 sec |
Auto Iris lens: VIDEO/DC |
Power: DC 12V |
Dimension: 115mmx60mmx48mm |
| |
|
ACE-614C |
Pick-up Device: 1/3" SONY CCD |
|
Effective Pixels: 752(h)x582(v) |
Horizontal Resolution: 480 Lines |
Minimum Illumination: 0.1 lux |
S/N Ratio: More than 52DB |
| Electronic Shutter: |
1/50~1/100.000 sec |
Auto Iris lens: VIDEO/DC |
Power: DC 12V |
Dimension: 115mmx60mmx48mm |
| |
|
ACE-615C |
Pick-up Device: 1/3" SONY CCD |
|
Effective Pixels: 752(h)x582(v) |
Horizontal Resolution: 480 Lines |
Minimum Illumination: 0.01 lux |
S/N Ratio: More than 60DB |
Electronic Shutter: 2X Zoom |
Auto Iris lens: VIDEO/DC |
Power: DC 12V |
| Dimension: 115mmx60mmx48mm |
| |
|
|
